The Autel MaxiSYS MS906 MAX diagnostic scanner from Logic Bart is a professional automotive diagnostic tool designed for workshops, vehicle service centers, and automotive technicians. It features a large 10.1-inch touchscreen and an Android operating system. The device supports full-system diagnostics, reading and clearing diagnostic trouble codes, viewing live data, performing bidirectional active tests, and carrying out a wide range of service, coding, and adaptation functions depending on vehicle compatibility.
A professional diagnostic scanner for testing vehicle electronic systems.
Supports full-system scanning of compatible vehicle control modules.
Helps read and clear diagnostic trouble codes and view freeze-frame data.
Displays live vehicle data with graphical monitoring during diagnosis.
Supports bidirectional control and active testing for accurate fault identification.
Provides coding, adaptation, and programming-related functions for supported vehicles and systems.
Includes the MaxiVCI V200 wireless communication interface for convenient movement around the vehicle.
Suitable for professional workshops, automotive service centers, and vehicle diagnostic technicians.
Large 10.1-inch high-resolution touchscreen for clear diagnostic data display.
Octa-core processor for fast software operation and diagnostic performance.
128 GB internal storage with 4 GB RAM.
Supports Auto Scan 2.0 for faster scanning of vehicle systems.
Provides more than 40 commonly used service and maintenance functions.
Supports active tests and bidirectional control on compatible systems.
Supports coding and adaptation functions depending on the vehicle and coverage level.
Compatible with modern CAN FD and DoIP communication protocols.
Allows diagnostic reports to be shared through QR codes, messages, or email.
Supports Wi-Fi printing for creating professional customer reports.
Can be used for battery testing and videoscope inspections with compatible optional accessories.
Supports ADAS calibration applications when used with the required software and equipment.
Connect the MaxiVCI V200 interface to the vehicle’s OBD diagnostic port.
Turn on the tablet and select the vehicle manufacturer, model, and production year.
Use the automatic scanning function to identify vehicle systems and retrieve faults.
Read and clear diagnostic trouble codes from supported electronic systems.
View live data and monitor changes while the vehicle is operating.
Use active tests to electronically activate selected components and check their response.
Perform service functions such as oil reset, electronic parking brake service, brake bleeding, and DPF regeneration, depending on vehicle compatibility.
Confirm that the required vehicle and function are supported before performing coding or adaptation procedures.
Maintain a stable vehicle battery voltage during sensitive coding or programming operations.
Brand: Autel.
Model: MaxiSYS MS906 MAX.
Type: Professional automotive diagnostic scanner.
Operating system: Android 10.
Display: 10.1-inch LCD touchscreen.
Display resolution: 1920 × 1200 pixels.
Processor: Octa-core processor.
RAM: 4 GB.
Internal storage: 128 GB.
Memory card support: Up to 256 GB.
Battery: 11,600 mAh lithium-polymer battery.
Rear camera: 13 MP.
Vehicle communication interface: MaxiVCI V200.
Connectivity: Wi-Fi, Bluetooth 5.0, and GPS.
Supported modern protocols: CAN FD and DoIP.
Functions: Full-system diagnostics, code reading and clearing, live data, active testing, coding, and adaptations.
Service functions: More than 40 functions depending on vehicle compatibility and coverage.
Category: Automotive diagnostic and programming equipment.
Store the device inside its protective carrying case after use.
Keep it away from moisture, excessive heat, and direct impacts.
Charge the device using a compatible charger.
Update the diagnostic software regularly to access the latest available vehicle coverage.
Make sure the device battery is sufficiently charged before starting long diagnostic sessions.
Do not disconnect the communication interface during active testing, coding, or programming.
Verify vehicle and function compatibility before starting any procedure.
Use a vehicle battery support unit during operations that require stable voltage.
