Autel MaxiTPMS TPMS Programming Tool

Autel MaxiTPMS TPMS Programming Tool

A professional all-in-one tool for fast and accurate tire pressure monitoring system service!

The Autel MaxiTPMS ITS600 from Logic Part Store is an advanced handheld tool designed for diagnosing, programming, and relearning Tire Pressure Monitoring System sensors. It runs on the Android operating system and features a color touchscreen, providing technicians, tire shops, and automotive service centers with essential functions for reading sensor data, diagnosing TPMS faults, and programming compatible Autel MX-Sensors efficiently.

🛞 Autel MaxiTPMS TPMS Programming Tool Description:

• A professional tool designed for TPMS sensor diagnosis, programming, activation, and relearning.
• Activates tire pressure sensors, reads their information, and performs supported relearn procedures.
• Displays sensor ID, tire pressure, temperature, frequency, and battery status.
• Supports programming compatible Autel MX-Sensors using multiple programming methods.
• Provides a clear diagnostic interface for checking the condition of each tire sensor.
• Supports OBDII relearn procedures on compatible vehicle models.
• Features VINscan technology to help identify vehicle information quickly.
• Suitable for tire shops, automotive workshops, and professional service centers.

✅ Autel MaxiTPMS TPMS Programming Tool Features:

• Activates, reads, diagnoses, and relearns supported TPMS sensors.
• Reads and clears TPMS diagnostic trouble codes.
• Displays live TPMS data and the location of each sensor on the vehicle.
• Reads tire pressure, temperature, sensor frequency, sensor ID, and battery condition.
• Programs compatible Autel MX-Sensors to replace a wide range of original sensors.
• Supports multiple programming methods, including copy by activation, copy through OBD, automatic sensor creation, and manual input.
• Supports batch programming of compatible MX-Sensors to save time in busy workshops.
• Performs fast OBDII relearn procedures on supported vehicles.
• Allows the technician to adjust supported tire pressure placard values.
• Features VIN scanning, barcode scanning, and QR code scanning for quick vehicle identification.
• Equipped with a 5.5-inch color touchscreen and an easy-to-use interface.
• Connects wirelessly to the vehicle through a Bluetooth VCI interface.
• Supports Wi-Fi, Bluetooth, and USB Type-C connectivity.
• Includes selected automotive maintenance functions for compatible vehicles.
• Suitable for a wide range of American, Asian, and European vehicles, depending on software coverage.

🧰 Autel MaxiTPMS TPMS Programming Tool Uses:

• Activates TPMS sensors installed on the vehicle.
• Reads sensor information and checks sensor battery condition.
• Diagnoses faults within the Tire Pressure Monitoring System.
• Reads and clears TPMS-related diagnostic trouble codes.
• Programs new compatible Autel MX-Sensors before installation.
• Copies the identification number of an old sensor to a compatible replacement sensor.
• Performs sensor relearning after replacement or tire rotation.
• Matches newly installed sensors with the vehicle control module.
• Resets supported tire pressure reference values.
• Helps technicians identify damaged, inactive, or incorrectly programmed sensors.
• Vehicle make, model, and production year should be selected accurately before beginning any procedure.

📦 Autel MaxiTPMS TPMS Programming Tool Specifications:

• Brand: Autel.
• Model: MaxiTPMS ITS600.
• Product type: TPMS diagnostic and sensor programming tool.
• Operating system: Android 9.0.
• Processor: 1.5 GHz quad-core processor.
• Memory: 2 GB RAM and 64 GB internal storage.
• Display: 5.5-inch LCD touchscreen.
• Display resolution: 1280 × 720 pixels.
• Connectivity: Wi-Fi, Bluetooth, and USB Type-C.
• Battery: 5000 mAh lithium-polymer battery.
• Vehicle communication: Wireless Bluetooth VCI interface.
• Dimensions: Approximately 183 × 89 × 22 mm.
• Net weight: Approximately 368 g.
• Suitable for: Tire shops, automotive workshops, and service centers.
• Category: TPMS diagnostic and programming tools.
• Color: Red and black.

📦 Storage and Usage Tips:

• Fully charge the device before beginning sensor diagnosis or programming.
• Select the correct vehicle make, model, and production year before performing any procedure.
• Confirm vehicle and sensor compatibility before programming or relearning.
• Position the device close to the tire sensor during activation and data reading.
• Do not disconnect the VCI interface while communicating with the vehicle.
• Keep the device software updated to receive improved vehicle and sensor coverage.
• Store the device in a clean and dry place away from moisture and excessive heat.
• Protect the screen and device body from impacts, drops, and heavy pressure.
• Use a suitable charger and cable to protect the internal battery.
• TPMS programming and relearning procedures should be performed by an experienced technician.
• Available functions may vary according to the vehicle model, production year, region, and software version.
• Check the package contents before purchasing, as included accessories may vary depending on the supplier or product version
